E84AVTCE1122SB0​ Lenze inverter 8400 TopLine 230V 1.1kW / 1.5HP STO

The 8400 TopLine offers the maximum level of functionality and optimum drive behaviour within the 8400 series, providing precisely tailored solutions.
Furthermore, TopLine represents a costeffective solution for speed-controlled and position-controlled applications, as well as synchronised and positioning applications.
Cross communication between multiple TopLine units requires minimum wiring (3-core), as it runs via the separate axis bus. Alongside asynchronous motors, TopLine also supports dynamic synchronous motors via feedback.
Benefit from precisely tailored, cost-optimised Lenze drive units, consisting of prepared system cables, motors and gearboxes, feedback, brakes, fans and of course the 8400 TopLine.

Functions:

  • DC brake function
  • Flying restart circuit, PID controller
  • Sensorless vector control
  • "VFC eco" energy saving function
  • Sensorless control of synchronous motors (SLPSM)
  • Brake management for brake control with low rate of wear
  • Logic functions, comparator, counter, arithmetic function
  • Freely interconnectable function blocks
  • Point-to-point positioning (with and without feedback)
  • S-ramps for smooth acceleration and deceleration
  • Servo control for synchronous and asynchronous motors
  • Electrical shaft with adjustable ratio (electronic gearbox)
  • Positioning sequence control
  • KTY temperature sensor evaluation

Interfaces:

  • Memory modules, L-force diagnostics interface
  • DIP switch for CANopen (on board)
  • Integrated brake chopper
  • External 24 V supply
  • Digital inputs / outputs (8/4), analog inputs / outputs (2/2), relay
  • Slot for EtherCAT, EtherNET/IP, PROFIBUS or PROFINET communication module
  • PTC/thermal contact input
  • Resolver input and multiple encoder input
  • Axis bus (for cross communication, synchronisation)

Technical Data:

  • Manufacturer: Lenze
  • Rated power: 1,1 [kW] / 1,5 [HP]
  • Rated mains voltage: 1/N/PE 230 [VAC] 50 [Hz]
  • Output current:  5,5 [A]
  • Output frequencies: 0-599 [Hz]
  • Mounting location: control cabinet
  • Safety engineering: STO
  • Protection Rating: IP20
  • Dimensions: h215 x b70 x d214 [mm]
  • Weight: 2 [kg]
