ERBP018R300W Brake resistor 18 Ohm Watt
Required when braking larger moments of inertia or for longer periods of regenerative operation.
suitable for Lenze frequency inverters i550, 8400 StateLine, HighLine, TopLine
and Lenze servo inverters i750, i950, i9400
technical data:
- Manufacturer: Lenze
- Permanent power: 300 Watt
- Rated resistance: 18 Ohm
- Max. operating voltage: 800 VDC
- Thermal capacity: 30 kJ
- Protection rating: IP23
- Approbation: cURus
- Dimension: H320 x W122 x D42 mm
- Weight per piece: 1,36 kg
