ERBP180R300W Brake resistor 180 Ohm 300 Watt
Required when braking larger moments of inertia or for longer periods of regenerative operation.
suitable for Lenze frequency inverters i550, 8400 [StateLine, HighLine, TopLine]
and Lenze servo inverters i750, i950, i9400
technical data:
- Manufacturer: Lenze
- Permanent power: 300 Watt
- Rated resistance: 180 Ohm
- Max. operating voltage: 800 VDC
- Thermal capacity: 45kJ
- Approbation: cURus
- Dimensions: H122 x W285 x D41 mm
- Weight per piece: 1,36 kg
