E84AYCPMV PROFINET communication module
Used to connect the 8400 StateLine, HighLine, or TopLine to PROFINET.
Features:
- 5 LEDs zur Statusanzeige
- 2 Anschlüsse RJ45 mit LED für Link und Activity
- TCP/IP-Kanal
- Anschlussmöglichkeit für separate 24-V-Versorgung
technical data:
- Manufacturer: Lenze
- Type: E84AYCERV
- Module type: Communication module
- Characteristic: PROFINET
- Connections: 2x RJ45 EtherNet
- Communication: one TCP/IP address, one device name
- External power supply: 24 VDC
- Baud rate: 100MBit/s
- Telegram: up to 16 process data words
- Protection class: IP20
- Cable length: up to 100m
