INTORQ BFK458-14E Stator 24VDC 60Nm
Electromagnetically released spring-applied brakes are used wherever masses in motion have to be decelerated as quickly as possible or where masses must be held in a defined position.
The main components of the modular system INTORQ BFK458 is the basic modules E (adjustable braking torque).
The greatest degree of flexibility is achieved for a broad range of applications by combining the basic modules E with specific modules.
Basic module E (adjustable braking torque) : unscrewing the centrally located torque adjustment ring can reduce the spring force and, with it, the braking torque.
technical data:
- Manufacturer: Intorq/Kendrion
- Type: INTORQ BFK458-14E
- Manufacturer's Part Number: 00521373
- Size: 14
- Design: E (with torque adjustment ring)
- Rated voltage: 24 VDC
- Characteristic torque: 25 - 60 Nm
- Weight: 6 kg
